Kelvin Hughes Launches its New Electronic Chart Display and Information System

Kelvin Hughes is pleased to announce the launch of its latest Electronic Chart Display and Information System (ECDIS) which is type approved to meet the latest International Hydrographic Office (IHO) and International Maritime Organisation (IMO) standards.

Designed for both commercial ships and naval and coastguard patrol vessels, the new ECDIS offers an optional mil-spec processor with advanced LED display hardware in a fully integrated, easy to install and retrofit, console package. It is available as a standalone ECDIS or as part of a truly multifunction bridge display network with multiple operator positions.

The benefit of a multifunction networked solution

With the advance of paperless bridges, the ability to view the chart from any bridge display position via a dual network, not only reduces the workload with distributed chart corrections, user-defined graphics and routes, but also eliminates the single point of failure as all positions in effect become potential ECDIS back-up displays.

Benefits of the Version 4 presentation library

The ECDIS uses the latest IHO standards and specifically the latest presentation library, version 4 within S-52. This contains instructions for the drawing engine within the ECDIS on how to display symbols, colours and line styles on the screen and brings greater consistency to the display of ENC data while reducing alarm fatigue.

InstaCHART

The efficient software architecture dramatically reduces the waiting time for the user when loading ENC cells.

  • ENC installation is now twice as fast.
  • Chart redraw when altering the zoom level is almost instantaneous with no black screen.

New features

The Kelvin Hughes ECDIS comes with a host of new and improved features to benefit the user:

  • Look ahead (marker and depth areas relevant to the ships course at an adjustable time period).
  • Anchor watch (visual and audible alarm of actual position in relation to swing circle).
  • Anchor dragging risk (notifies if the anchor may be dragging and exceeds the new IEC 61174 standard).
  • Navtex compatibility (removes the need to print messages as they can now be displayed on screen).
  • Maximise chart area (provides the ability to hide the menu side bar).
  • Best scale option (automatically selects the best chart viewing scale).
  • Admiralty Information Overlay (AIO via CAES)
  • AIS and radar target layers (supports additional layers).
  • One click chart updates and permit renewal.
  • Remote diagnostics.
  • Improved route planning tools.

The state of the art LED widescreen display is available in 22″ and 26″ sizes and is an easy to install console display with an integrated 5th generation processor and 64bit operating system which can be easily integrated into any bridge or operations room.

The new ECDIS is being demonstrated on the Kelvin Hughes stand at DSEI on stand S4-110 as part of the interactive tactical navigation system being presented for navies and coastguards.
